How To Reattach Outside Rear Car Door Window Frame Moulding Trim 2007 Honda Accord


To reattach the outside rear door window frame moulding trim on a 2007 Honda Accord:

  1. Remove the door panel to access the trim
  2. Clean off any old adhesive residue from the door frame
  3. Apply new automotive trim adhesive tape to the back of the moulding trim
  4. Carefully align the trim and press it firmly onto the door frame
  5. Secure the ends with the original clips or replace if damaged
  6. Reinstall the door panel

What Tools and Materials Are Required to Reattach the Moulding Trim?

To reattach the outside rear door window frame moulding trim on your 2007 Honda Accord, you will need the following tools and materials:

  • Plastic trim removal tool or flathead screwdriver
  • Phillips head screwdriver
  • 8mm socket wrench
  • Adhesive remover wheel
  • Heat gun or hair dryer
  • Cleaning cloth
  • Rubbing alcohol
  • Replacement moulding trim
  • Automotive trim adhesive tape (like 3M 03614 Scotch-Mount Molding Tape)

Having these items on hand before starting the project will make the process go smoothly.

How Do I Remove the Door Panel to Access the Moulding Trim?

To access the moulding trim, you first need to remove the rear door panel:

  1. Use a trim removal tool or flathead screwdriver to pry off the door panel clips around the perimeter, starting at the bottom corner.
  2. Lift up the door panel to release it from the top clips.
  3. Disconnect any electrical connectors for the window and lock controls.
  4. Remove the 8mm bolts securing the door handle and trim behind it.
  5. Carefully lift the door panel up and away from the door.

With the door panel removed, you will have clear access to the moulding trim.

What Are the Steps to Remove the Old Moulding Trim and Any Remaining Adhesive?

Here are the steps to remove the old moulding trim and adhesive residue:

  1. Locate the moulding trim screws at each end and remove them with a Phillips screwdriver.
  2. Use a plastic trim tool to gently pry up the end of the moulding trim.
  3. Apply heat from a heat gun or hair dryer to soften the adhesive as you slowly pull the trim piece away from the door frame.
  4. With the trim fully removed, use an adhesive remover wheel attached to a drill to buff away any remaining adhesive residue on the door frame.
  5. Wipe down the door frame with rubbing alcohol to remove any adhesive particles and dirt.

Take your time with this process to avoid damaging the paint or metal underneath.

How Do I Clean and Prepare the Surface for the New Moulding Trim?

Properly preparing the door frame surface is critical for the new moulding trim to adhere correctly:

  1. Closely inspect the door frame for any dents, deep scratches or corrosion. Repair these imperfections before proceeding.
  2. Thoroughly clean the metal door frame with rubbing alcohol and a lint-free cloth to remove any remaining dirt, oils or adhesive residue.
  3. Allow the door frame to fully dry.
  4. Test fit the new moulding trim to ensure it aligns correctly with the screw holes and contours of the door frame. Make any necessary adjustments.

A clean, dry and properly aligned surface will provide the best base for the new adhesive to form a strong bond.

What Is the Correct Method for Applying Adhesive to the New Moulding Trim?

The key to a secure and lasting moulding trim installation is applying the adhesive tape correctly:

  1. Make sure the moulding trim and door frame are at room temperature before applying the adhesive.
  2. Cut the automotive adhesive tape to the same length as your moulding trim.
  3. Carefully apply the tape to the back of the moulding trim, ensuring it is straight and fully adhered without any air bubbles.
  4. Avoid touching the adhesive surface with your fingers to keep it clean and oil-free.

Proper application of the adhesive tape will provide maximum contact area and bonding strength with the door frame.

How Do I Properly Align and Attach the New Moulding Trim to the Door Frame?

Follow these steps to accurately attach the new moulding trim to your Accord’s door frame:

  1. Peel back 1-2 inches of the red backing tape on the adhesive, exposing the sticky surface.
  2. Align the moulding trim with the screw holes and contours of the door frame. The trim should sit flush without any gaps.
  3. Once positioned, press the exposed adhesive area firmly against the door frame.
  4. Slowly peel back more of the red backing tape while applying pressure to adhere the trim to the frame, working your way from one end to the other.
  5. Reinstall the moulding trim screws at each end and tighten securely.
  6. Apply firm pressure along the entire length of the trim for 30-60 seconds to ensure good adhesion.

Patience and attention to detail during alignment and attachment will ensure a factory-like fit and finish.

What Are Some Common Mistakes to Avoid When Reattaching the Moulding Trim?

Avoid these common mistakes to achieve the best results when reattaching your Accord’s moulding trim:

  • Not cleaning the door frame thoroughly. Any dirt or oil will prevent the adhesive from bonding securely.
  • Touching the adhesive surface. Oils from your skin can interfere with proper adhesion.
  • Applying the adhesive in extreme temperatures. Most adhesives work best between 60-80°F.
  • Rushing the adhesive application. Take your time to apply it evenly and smoothly.
  • Not applying consistent pressure. Maintain firm pressure on the trim for 30-60 seconds after installation to ensure complete contact.

By sidestepping these pitfalls, your moulding trim will be affixed correctly and have a long-lasting, seamless appearance.

How Do I Ensure a Secure and Long-Lasting Bond Between the Moulding Trim and the Door Frame?

To guarantee a secure and enduring bond between the moulding trim and door frame, keep these tips in mind:

  • Only use automotive-grade adhesive tape that is designed to withstand exterior conditions and temperature changes.
  • Ensure the door frame surface is immaculately clean and free of any contaminants before adhering the trim.
  • Apply firm, steady pressure to the moulding trim during attachment to eliminate any gaps or air pockets.
  • Allow the adhesive to cure according to the manufacturer’s directions before exposing it to moisture or extreme temperatures.
  • Regularly inspect the moulding trim to check for any signs of separation or lifting, and address any issues promptly.

By following these guidelines, your Accord’s newly attached moulding trim will remain solidly bonded and looking great for years to come.

Are There Any Additional Tips or Tricks for a Successful Reattachment of the Moulding Trim?

Here are a few extra tips and tricks to help make your moulding trim reattachment project a success:

  • If the old adhesive residue is stubborn, try using a citrus-based adhesive remover or a product like Goo Gone to help dissolve it.
  • A plastic razor blade can be helpful for scraping off any remaining adhesive without damaging the paint.
  • Warming up the adhesive tape with a hair dryer before applying it can help it conform better to the curves and contours of the moulding trim.
  • Double-check the alignment and fitment of the moulding trim before fully adhering it to the door frame.
  • If you accidentally adhere the trim incorrectly, you may be able to carefully pull it off and reposition it if you act quickly before the adhesive fully sets.

By employing these additional tips and tricks, you’ll be well on your way to a flawless and professional-looking molding trim reattachment on your 2007 Honda Accord.
